- Test Voltages of 100/250/500/1000 VDC
- Insulation resistance measurements up to 1999 MΩ
- 0 to 600 VAC Measuring Range
- Guard terminal to eliminate surface leakage current
- Battery Operated
- Large easy-to-read 3Ω LCD display
Megger 210600 Extended Range Insulation Resistance Testers are ideal instruments when high ranges are needed for measuring insulation resistance. It provides excellent test voltage regulation and an external guard terminal to eliminate surface leakage current from the measurement. The instrument is all electronic; it generates a regulated dc high voltage and use low-zero-drift, high-accuracy circuits, with high current sensitivity. Designed for portability, each is enclosed in a molded, impact-resistance, flame-retardant case.
The instrument is protected for connection to power distribution systems up to 300 V Line-Ground and 500 V Line-Line for Installation Category III. This relates to transient overvoltage likely to be found in fixed installation wiring.
O/C Test Voltage (VDC) 100/250/500/1000 Insulation Resistance Range 0 to 199.9 at all test voltages
0 to 1999 kΩ at 500 and 1 kV
Resistance Range 0.01 to 1.999 kΩ
2.00 to 19.99 kΩ
(at 4.3 VDC Open Circuit)
Power Source 6 AA Cells Voltage Range 0 to 600 VAC or presence of DC Dimensions 7 H x 5 W x 5 D in.
180 H x 125 W x 125 D mm
- 1 - 217720 Carrying Case
- 1 - 210949 Test record cards (universal)
- 1 - EV6172-373 Instruction Manual
